In Associate with MAMMUT Building Syatem, UAE
SPECIFICATION:
Built-up Section : Hot Rolled Plate - ASTM A570 / A572-50 or equivalent Fy = 345 MPa
M. S. Purlin and Girt : Rolled Formed High Strength steel. Minimum yield stress 345 MPa (followed to offer)
Galvanized Steel Purlin & Girt: Rolled Formed High Strength Zinc coated steel. Minimum yield stress 345 MPa (followed to offer)
Bracing
i) Angle Bracing
Hot Rolled MS Angle, A36
ii) Cable Bracing
Cable of High Strength Wire
Glass Wool Insulation
a) Density - 10 ~ Kg/M3 minimum
b) Thermal Conductivity - 0.0265-0.0284 W /mk at 30º C
c) Glass Wool Blanket with separate aluminum foil
Poly Foil Insulation
a) 4mm thick poly foil insulation with or without glue
b) Thermal conductivity 0.029 W/mk@ 27º C
Bubble (McCool) Insulation
a) Thermal conductivity - 0.001 W/m.k at 30º C
Mezzanine Deck Panels
Made of High Strength M.S./Galvanized Steel strip (BONDEK XP) minimum yield Strength 345 Mpa (followed to offer)
Wind Turbine (Natural) Ventilator
a) Designed & constructed from 100% strong light weight Aluminum
b) Good for smoke/heat release ventilation
c) Leak proof and operates under wind load and without electricity
d) Dia of ventilator : 14" /18" /20"
